1A1R Diamond Grinding Wheels for Cutting Carbide and Grinding Grooves
1A1R Cutting-off wheels. For Carbide Cutting And Grinding Grooves Cutting Optical Glass Quartz Sapphire Grind Disc. This wheel is used in cutting machines, surface grinders, outside diameter grinders, and machining centers.
Brief Introduction
| BRIEF DESCRIPTION: 1A1R Thin Resin Diamond Grinding Wheel (resin bonded diamond cut off discs)For Carbide Cutting And Grinding Grooves Cutting Optical Glass Quartz Sapphire Grind Disc Excellent value in routine cutoff procedures for carbide blanks.  |
Product Size
| Bond | Resin bond, Metal bond, Electroplated bond |
| Types | 1A1R Diamond Grinding Wheel / 1A1R diamond cut off wheel |
| Application | cutting & grooving carbide, glass, ceramic, magnetic materials, and HSS |
| Diameter | from 5′′ (125mm) to 16′′ (400mm). |
| Thickness | 0.3mm – 2.8mm |
| Tolerance | ±0.005mm |
| Feature: 1. Use our own durable synthetic diamond abrasive. 2. The life of the grinding wheel is longer. 3. Resin bond for self-sharpening and even grit distribution. |
|
resin bonded diamond cut off wheel 1a1r Diamond Grit Size Designation Range
| Mesh Size | ||||
| 50# | 60# | 80# | 100# | 120# |
| 140# | 170# | 200# | 230# | 270# |
| 325# | 400# | 600# | 800# | 1000# |
| 1500# | 2000# | 2500# | 3000# | 4000# |
| 5000# | 6000# | |||
Product Application
| Diamond cutting wheel： For cutting carbide, glass, ceramic, silicon, quartz, glass fiber plastic (GRP), graphite, QFN and super hardened steel, etc. CBN cutting wheel： In cutting hardened steel, cast iron, high-speed steel, magnetic materials, bearing steel, die steel, etc. 1A1R Resin Diamond Cutting Wheel For Optical Components  |
|
 |
 |
 |
 |
